Wharfedale Pro EVP-X12M MKII EVP-X MKII Series 300W Passive Stage Monitor 12 Inches SKU# WD-EVP-X12M MKII

Equipped with a custom Wharfedale Pro 12″ LF driver with a 2.0″ voice coil and a 1.75″ HF compression driver, it delivers focused sound with clarity and definition across the full frequency range. Handling 300 W AES (600 W programme / 1200 W peak) and reaching 129 dB max SPL @ 1 m, EVP-X12M MKII ensures powerful stage monitoring even in high-volume environments.

A 90° x 60° elliptical waveguide provides controlled HF dispersion for consistent coverage across performance areas. When additional brightness is needed, the onboard +3 dB HF boost switch offers instant tonal lift.

Designed for life on stage, EVP-X12M MKII is protected by a durable carpet finish and steel grille, with rubberised 4-way carry handles for easy transport and setup. 4 pole speaker connectors and 1/4″ jack inputs ensure flexible connectivity.

A rugged, dependable stage monitor that keeps performers locked into the mix with power, clarity, and confidence.

eady to rumble? With 1200 W peak power and 129 dB max SPL, the Wharfedale Pro EVP-X12M MKII isn't just loud - it's legendary.

Elliptical Waveguides

Full range models feature a 90° x 60° Elliptical Waveguide

In real-world terms this means that the higher frequencies can be heard with definition at 90° in the horizontal plane, and 60° in the vertical.

All full range models in the EVP-X MKII series use this same elliptical waveguide design which makes for controllable coverage when using multiple EVO-X series loudspeakers.

Tough Carpet

Each EVP-X MKII PA speaker and subwoofer is protected by a durable carpet covering and steel grille.

The MKII version features a 4-way carry handle and a dual angle pole mount making it both portable and versatile for varying installation applications, ensuring the HF sound is directed straight at your audience.

Turn it up, feel the punch, and let your performance shake the room - this floor monitor was born to roar.

• 12″ floor monitor
• 1.75″ voice coil HF driver
• 12″ LF driver with 2.0″ voice coil
• 300 watts AES (RMS)
• 600 watts Programme
• 1200 watts Peak
• 129 dB Max SPL @ 1 meter
• Carpet covered hard working PA speakers
• 4-way rubberized handles
• Elliptical 90° x 60° dispersion
• Full series lineup consisting of 8 models
• NL4 (speakON compatible) and 1/4" connectors
• +3 dB HF Frequency boost switch
• Subwoofers feature internal crossover

• Active or Passive: Passive
• System Type: Floor Monitor
• Configuration: 2-way
• System Continuous Power: 300 W
• System Programme Power: 600 W
• System Peak Power: 1200 W
• Max SPL @ 1m: 129 dB
• Frequency Response (+/-3 dB): 60 Hz - 20 KHz
• Frequency Range (-10 dB): 55 Hz - 20 KHz
• Bi-amp Mode Switch: No
• Bluetooth: No
• IP Certification: None
• Driver Brand: Wharfedale Pro
• LF Driver Size: 12"
• LF Voice Coil Size: 2"
• LF Rated Impedance: 8 Ω
• LF Power (RE:AES2-2012); 300 W
• HF Driver Type: Compression Driver
• HF Voice Coil Size: 1.75"
• HF Diaphragm Material: Titanium
• HF Exit Size: 1"
• HF Power (RE:AES2-2012): 40 W
• HF Rated Impedance: 8 Ω
• VHF Nominal Coverage (H x V): 90° x 60°
• Preset Library: Yes
• Input Connector: 2 x 4 Pole Speaker Connector / 2 x 1/4" Jacks
• Waveguide Type: Elliptical
• Enclosure Material: Particle Board
• Grille Material and Finish: Steel Black
• Finish: Black Carpet
• Handles: 2
• Deployment: Ground
• Pole Mount: None
• Brackets Included: No
• Rigging: No
• Sensitivity 2.83v / 1m: 98 dB
• System Rated Impedance: 8 Ω
• Crossover Frequency: 2.4 kHz
• Recommended HPF = BW 18 dB/OCT.: 55 H
• Transformer (T): No
• Included Accessory: User Manual

• Height 480 mm / 18.9″
• Width Front 616 mm / 24.25″
• Width Rear 616 mm / 24.25″
• Depth 490 mm / 19.29″

• Net Weight: 17.96 kg / 39.5 lbs
• Gross Weight: 20.56 kg / 45.2 lbs
