Ashly CA-1.04 Power Amplifier 4 x 1000W/4 Ohms, 500W/8 Ohms, 1000W/70V SKU# CA-1.04
Experience top notch efficiency from the Ashly Audio CA-1.04. From their new CA series, this 4 channel power amp is an ultra-efficient D-MAX Class D design with Dynamic Power Factor Correction and 70 V capability. The solid metal front panel features adjustable Input Gain per channel. Switchable HPF and Clip limiter are also controllable per channel. Bi-lateral SailFlow cooling ensures quality performance and Euroblock and XLR combo connectors are designed to be installer friendly. Simple and powerful results from the audio professionals at Ashly.
Features
- 4 channels, 4 x 1000 Watts @ 4 Ohm
- Combo XLR-1/4" & Euroblock Inputs
- Euroblock Output Connectors
- Ultra-efficient D-MAX Class D Design
- DPFC (Dynamic Power Factor Correction)
- Adjustable front panel Input Gain per channel with lock-out
- Bi-lateral SailFlow cooling
- Installer-friendly Euroblock and XLR combo connectors
- Switchable HPF and Clip Limiter per channel
Specifications
- Channels: 4
- Wattage (at 2 Ohms): 1000 W
- Wattage (at 4 Ohms): 1000 W
- Wattage (at 8 Ohms): 500 W
- Wattage (at 8 Ohms [bridged]): 1000 W
Constant Voltage
- 1000 W, 70 V (per channel)
- 2000 W, 100 V [bridged]
Items Included
- Ashly CA Series High-Efficiency 4-Channe
- Power Amplifier
Limited 5 Year Manufacturer Warranty
